The DEA Livi 600 (model 6X/M) is an Italian 230V sliding gate motor. It takes gates up to 600 kg. One number decides whether it suits your gate, and it is not the 600 kg. It is the 60 openings a day DEA allows on a 5 metre gate. We stock it in Al Khuwair for OMR 158.000 and fit it across Oman.
DEA Livi 600 daily limit: 60 cycles on a 5 metre gate
| Gate | DEA limit |
|---|---|
| Cycles per hour, 5 m gate | 18 |
| Cycles in 24 hours, 5 m gate | 60 |
| Motor thermal cut out | 140°C |
Each time a car leaves and returns, the gate does two cycles. So 60 cycles is about 30 car trips a day. A family villa sits well inside that. A shared compound, a shop or a staff yard does not. Many seller pages call this motor “heavy duty” and give no daily figure. DEA’s manual does.
The motor moves the gate at 10 metres a minute. A 5 metre gate takes about 30 seconds to open.
What the DEA Livi 6X/M name means
DEA sells one Livi range under many near identical names. The letters decide what you get.
| Letters | Meaning |
|---|---|
| X | Motor runs on 230V |
| 24X | Motor runs on 24V, 80 W, 210 N |
| XE | Analog control unit 212E |
| M | Magnetic limit switches |
| BOOST | High speed motor, 16 m/min |
This page is the 6X/M: 230V, magnetic limit switches, NET230N control unit. A listing that only says “Livi 600” could be any of these, so check the label before you buy parts.
DEA Livi 600 or DEA Livi 900, which pulls harder
| Livi 6X/M | Livi 9X/M | |
|---|---|---|
| Maximum gate weight | 600 kg | 900 kg |
| Maximum power | 320 W | 450 W |
| Maximum thrust | 340 N | 490 N |
| Cycles per hour, 5 m gate | 18 | 11 |
| Cycles per day, 5 m gate | 60 | 40 |
| Weight with packaging | 11 kg | 12.5 kg |
The bigger motor pulls harder, but DEA allows it fewer cycles a day, not more. Pick the 900 for a heavy gate that opens a few times. Pick the 600 for a lighter gate that opens more often.
DEA Livi 600 in Oman heat and dust
The motor works from minus 20°C to plus 50°C, and is rated IP44. IP44 covers splashes and objects over 1 mm, but not fine dust. Muscat and Sohar summers can reach 50°C inside a closed motor housing, which is the top of its range. Keep the cover shaded and the track clear of sand.
DEA asks you to clean the cover, check the screws and test the release lever every 6 months.
DEA Livi 600 sliding gate motor specifications
| Model | DEA Livi 6X/M |
|---|---|
| Maximum gate weight | 600 kg |
| Power supply | 230 to 240V AC, 50/60 Hz |
| Maximum power | 320 W |
| Maximum thrust | 340 N |
| Gate speed | 10 m/min |
| Duty on a 5 m gate | 18 cycles per hour, 60 per day |
| Limit switches | Magnetic |
| Motor control | Encoder with obstacle detection |
| Control unit | NET230N with built in 433 MHz receiver |
| Rack pinion | Z16, module 4 |
| Protection rating | IP44 |
| Operating temperature | Minus 20°C to plus 50°C |
| Weight | 11 kg with packaging |
Safety, slowdown and the magnet gap
The control unit has an anti crushing sensor, speed control and a slowdown at both ends of travel. The magnets must sit 15 to 30 mm from the sensor. Over 30 mm and the limit may not register. We set the gap and the pinion, 1 to 2 mm clear of the rack, during installation.
What is included with the DEA Livi 600
- One DEA Livi 6X/M motor with integrated NET230N control unit and receiver
- Anchor base and release key
Quoted separately: remotes, photocells, a flashing light, the rack, foundation concrete and installation. See remotes and accessories for more. Tell us your gate length and we will quote the rack and the rest as one package.
Installing a DEA Livi 600 sliding gate motor in Oman
Our engineer checks the track, wheels and balance. The gate must stay put when stopped halfway. We fix the base, set the rack, fit the magnets and wire the photocells. Then we set the force, speed and slowdown, and test the anti crushing sensor.
Sliding gate motor installation for villas across every governorate
We install in Muscat, Sohar, Nizwa, Salalah, Sur, Duqm and every other governorate. See our sliding gate motors, gate spare parts or our installation service. For a busier gate, ask about the Nice Robus 600.
Common questions
How many times a day can the DEA Livi 600 run?
DEA allows 60 cycles in 24 hours and 18 an hour on a 5 metre gate. That is about 30 car trips a day. A busier gate needs a different motor.
Is the DEA Livi 600 a 230V or a 24V motor?
This 6X/M runs on 230V. DEA also makes a 24V Livi 600 with 80 W and 210 N. Check the letters on the label.
Does the DEA Livi 600 work in Oman summer heat?
It is rated from minus 20°C to plus 50°C and IP44. Summer sits at the top of that range, so keep the cover shaded and the track clear.
What does the DEA Livi 600 cost?
OMR 158.000 for the motor with its control unit and receiver. Remotes, photocells and rack are quoted separately. Payment is cash on delivery.
