The BFT Athos AC A40 AL is an Italian 230V swing gate motor. It takes gate leaves up to 4 metres long and 400 kg. The AL means motor left. BFT sells a matching AR, motor right, and a complete two motor kit. Choose the right one before you order. We stock it in Al Khuwair for OMR 232.000 and fit it across Oman.
BFT Athos AC A40 AL means motor left
| Model | What BFT calls it |
|---|---|
| Athos AC A40 AL, this page | Motor left |
| Athos AC A40 AR | Motor right |
| Athos AC KIT A40 | Complete kit for swing gates |
The AL and AR have the same figures. They differ in the hand of the motor. Tell us which side the motor sits, and which way each leaf opens. We will confirm the hand before we order. A double leaf gate has two leaves, so you will usually need a motor for each. The other leaf takes the BFT Athos AC A40 AR. We quote the pair with you on WhatsApp before you pay. For a complete pair with remotes and photocells, see the BFT Athos AC A40 kit.
BFT Athos AC A40 AL cycles per hour in Oman heat
| Temperature | BFT cycles per hour |
|---|---|
| 20°C | 9 |
| 55°C | 4 |
BFT cuts the allowed cycles as the air gets hotter. Oman summers push the motor towards the lower figure. BFT classes the use as semi intensive. A family villa fits well. A shared gate or a staff yard does not, so ask us first.
BFT Athos AC A40 AL takes a long leaf, but a light one
| Athos AC A40 AL | Athos AC A25 AL | |
|---|---|---|
| Maximum leaf length | 4 metres | 2.5 metres |
| Maximum leaf weight | 400 kg | 700 kg |
| Useful rod stroke | 400 mm | 300 mm |
| Time to open 90° | 16 seconds | 14 seconds |
Both limits apply. A leaf inside the length but over the weight is outside the rating. So is the reverse. The A40 suits a long leaf in light aluminium or a hollow frame. For a short, heavy leaf, see the BFT Phobos AC A25.
BFT Athos AC A40 AL protection and temperature
The motor is rated IP54 and works from minus 20°C to plus 55°C. IP54 covers dust that cannot harm the motor, and splashing water. The shells are die cast aluminium, and the transmission uses a bronze crown. Keep the rod clean of sand, and keep the cover on.
BFT Athos AC A40 AL swing gate motor specifications
| Model | BFT Athos AC A40 AL, part number 2611769 |
|---|---|
| Motor hand | Left |
| Maximum leaf length | 4 metres |
| Maximum leaf weight | 400 kg |
| Power supply | 230V AC |
| Power consumption | 280 W |
| Useful rod stroke | 400 mm |
| Maximum opening angle | 110° |
| Time to open 90° | 16 seconds |
| Limit switch | Work time, with slowdown |
| Locking and release | Mechanical lock, triangle key release |
| Impact reaction | Electronic clutch |
| Control unit | ALENA SW2 |
| Protection rating | IP54 |
| Operating temperature | Minus 20°C to plus 55°C |
| Country of origin | Italy |
What is included with the BFT Athos AC A40 AL
- One BFT Athos AC A40 AL motor, motor left
- One ALENA SW2 control unit with built in receiver
- Front and rear fixing brackets
- One triangle release key
Quoted separately: the AR motor for the other leaf, remotes, photocells, a flashing light, an electric lock and installation. See remotes and accessories for the rest.
Installing a BFT Athos AC A40 AL swing gate motor in Oman
The front and rear brackets line up, so the motor fits even in a pillar niche. Our engineer checks the hinges and the leaf balance first. We fix the brackets level, set the work time and slowdown, and test the electronic clutch. Then we wire the photocells and measure the impact force. A leaf that drags on its hinges will stall the motor, so we fix that first. We also show you how to use the triangle key in a power cut. Keep that key somewhere you can find in the dark.
Swing gate motor installation for villas across every governorate
We install in Muscat, Sohar, Nizwa, Salalah, Sur, Duqm and every other governorate. See our swing gate motors, gate spare parts or our installation service.
Common questions
What does AL mean on the BFT Athos AC A40?
BFT describes the AL as motor left. The AR is motor right. They have the same figures. We confirm the hand before we order.
How many cycles an hour can the BFT Athos AC A40 AL run?
BFT lists 9 cycles an hour at 20°C and 4 an hour at 55°C. Oman summer heat pushes towards the lower figure.
Can the BFT Athos AC A40 AL move a heavy 4 metre leaf?
No. It takes 4 metres only at up to 400 kg. For a heavy leaf up to 2.5 metres, ask about the BFT Phobos AC A25 at 700 kg.
What does the BFT Athos AC A40 AL cost?
OMR 232.000 for the left hand motor with its control unit. Payment is cash on delivery. Installation is quoted separately.
Order the BFT Athos AC A40 AL in Oman
Send your leaf length, leaf weight and a photo of the pillars on WhatsApp to +968 75219236. You can also call +968 75219236. Visit us at Shop No 176, Way Street No 57, Block No 17/2, Al Khuwair, Muscat, Oman. We are open 9 am to 9 pm every day. Email contact@falajtech.com.
